Universal laboratory mill FNG
Impact mill with the possibility of adapting different grinding tools (hammers, paddles, spindles) to process different products with different granulometries in the same grinding body.
The main body is made of 316L single-piece machined stainless steel, and is designed for small-scale laboratory grinding plants. The FNG-00 has been designed for table-top installation. The motor and transmission are totally enclosed. Smaller and more compact, it nevertheless has the same features as a Forplex New Generation mill: variable speed, easy plate change, etc.
Operating principle
The material is fed into the centre of the crusher.
Crushing is achieved by impact and projection between the moving parts of the high-speed rotating rotor and the stationary parts.
The fineness of the product to be ground is determined by:
- The grinding equipment
- The perforation and type of screen ring
- The feed rate
- The air flow rate
- The rotational speed (max. 150 m/s)
Changing any of these parameters will alter the particle size distribution of the finished product.
Safety
- Shaft-in-sleeve design
- Air/nitrogen purging of the front bearing to eliminate any risk of contamination when processing multiple products
- Door opening safety system
Options
Available in 304L or 316L stainless steel (other versions available on request)
Explosion-proof version (10 bar absolute)
Mirror-polished, Ra ≤ 0.2 max. for parts in contact with the product
Thermocouple well in the housing for temperature probe
Interchangeable internal shielding
Shaft line locking for frequent dismantling of grinding components
Construction compliant with pharmaceutical GMP criteria
Linear rotation speed: max. 150 m/s
General construction
- Welded steel construction
- Door fitted with multi-point hinges ensuring optimal sealing
Caractéristiques
- Flow rate (l/h): 0 to 50 l/h
- Particle size: 5 mm to 50 µm
- Batch size: 0 to 10 kg/h
- Power supply: 380 Volts
From laboratory trials to commercial success
Customise your laboratory grinder to suit your experiments.
Chassis
Hopper
Grinding tools
Mill
Throughput
Versions
Pin or hammer grinding tools ?
We’re here to help you choose.
Pin tool
- Fine and ultra-fine grinding
- Dry, non-clogging, brittle materials that are easy to grind.
- Dispersion of very fine agglomerated particles.
- Intensive mixing of different components through simultaneous grinding.
- This unit does not use a sieve ring, thereby avoiding the risk of clogging.
- The fineness of the grind is primarily determined by the rotational speed.
Hammer tool
- Fine, semi-fine, coarse and preliminary grinding.
- Friable to semi-hard, crystalline, brittle, oily and fibrous materials.
- Without a screen ring, the mill is used as a primary mill (granulator/crusher).
- The particle size of the product is controlled by the rotor speed, the perforations and the design of the screen ring.
The FNG grinder is also available as a complete unit with a digital display and a recipe system for your trials.
Research and development laboratories in the pharmaceutical, cosmetics and food industries require small-scale grinding equipment to carry out grindability tests on their products, with a view to scaling up production.
Taking into account the key requirements of R&D departments and laboratories, FORPLEX has completely redesigned its FNG00 laboratory equipment to offer a system that meets standards for safety, ergonomics, certification and contamination control.
Fully washable with water (IP65 rating, watertight interior), easily dismantled without tools, and featuring simplified operation, the FNG00 grinding station is suitable for all types of users.
Polyvalent
Interchangeable grinding tools
Operate on a fee-based system
Each method of grinding a product can be saved on the touchscreen
Compact
Fits through a standard door thanks to its compact size
Ergonomic
All tasks can be carried out at waist height, with no heavy components
Easy to clean
An easily removable, sealed and water-resistant unit (IP65)
Easy to move
Movement on wheels or a pallet
Reinforced safety
It is impossible to have an accident involving moving parts
Easy to start-up
All you need is a 400-volt power socket and a 6-bar compressed air supply
No visible wire
All the electrical components, including the motors and wiring, are located behind the shredder
Cryo (option)
Injection of liquid nitrogen for the grinding of moist and/or fatty products
Informations
Screw feed rate: from 0 l/h up to 50 l/h per batch
Grinder feed rate: from 0 l/h up to 50 l/h
Particle size: from 5 mm down to 50 µm
Batches to be ground: from 0 to 10 kg/h
Dimensions: 1027 mm (length) x 786 mm (width) x 1476 mm (height)
Power supply: 380 volts
Pharmaceutical-grade finishes: 316L stainless steel, Ra 0.8 (0.2 optional), material certificates 3.1 and food-grade compliance, ANIA, FDA, ATEX installation (optional). No retention points, stand-alone installation.
